Samsung 98" Public Display QB98R
3840x2160, 350 nits, Tizen, Speakers, DVI/2xHDMI/DP
Produktoplysninger
Samsung 98" Public Display QB98R
UHD display that engages customers with lifelike images through innovative and unique picture-enhancing features.
Engage customers with lifelike images through ultra high-definition resolution
Deliver UHD-level picture quality even with lower resolution content through innovative UHD upscaling technology and unique picture-enhancing features
New symmetrical, slim design simplifies installation and complements any environment
Time to upscale your display
Samsung’s new QB98R displays cut through the clutter to deliver best-in-class UHD resolution as well as intelligent UHD upscaling all in a slim design.

Incredible 4K picture quality
Samsung’s new QB98R provides ultra high-definition 4K resolution, creating lifelike images with sharper picture quality than ever before.

Intelligent UHD upscaling
Samsung’s cutting-edge intelligent UHD upscaling technology performs edge restoration and noise reduction to deliver perfect UHD picture quality even with lower resolution content. This “future-proof” solution ensures best-in-class picture quality regardless of the original content resolution.

Perfect view with non-glare display
The QB98R features reliable, non-glare panels that provide better visibility from all angles, anytime of day allowing businesses to deliver accurate information 24/7 in locations where clear and accurate information is crucial such as airports and commuter stations.

Powerful, all-in-one solution
SSSP is an all-in-one solution that simplifies installation and maintenance. With Tizen 4.0, businesses can enjoy easy development, reinforced capability with multiple web formats and standards and secured protection.

Empower Secure and Remote Collaboration
Samsung’s KNOX platform provides rigid three-layer protection while also securing and controlling USB and user network exchange through dedicated signage device management. With added security, businesses can facilitate remote, PC-free meetings without risk or complexity.

WiFi and Bluetooth built-in
Built-in WiFi and Bluetooth allow for more personalized and interactive services as well as simplifying how businesses showcase content. Whether it’s to make networking simpler or enabling interactive beacon technology in-store, QB98R displays help businesses move into the future of retail.

Tekniske detaljer
Producentens garanti (måneder) | 36 |
---|---|
Produkttype | LED-bagbelyst LCD-fladpaneldisplay |
Energiklasse | Klasse B |
Strømforbrug ved drift | 528 Watt |
Strømforbrug (Til-modus) | 372 W |
Energiforbrug om året | 543 kWt |
Diagonal klasse | 98" |
Kommercielt brug | Ja - digital skiltning |
Serie | QBR Series |
Platform | Tizen OS 4.0 |
Tv-tuner | Ingen radio |
TV Tuner Presence | Nej |
Video Grænseflade | HDMI |
HDMI Port Antal | 2 porte |
PC grænseflade | DVI, DisplayPort |
Billedforbedringer | Mega Dynamic Contrast Ratio, Intelligent UHD-opskalering |
Dimensioner | Uden stander |
Bredde | 219.42 cm |
Dybde | 7.53 cm |
Højde | 124.98 cm |
Vægt | 77.1 kg |
Opløsning | 3840 x 2160 |
---|---|
Display Format | 4K UHD (2160p) |
Billedformatforhold | 16:9 |
LCD-baggrundsbelysningsteknik | LED baglys |
Belægning | Anti-genskin, 25% Glass Haze |
Billedkontrastforhold | 4000:1 |
Klarhed | 350 cd/m² |
Synsfeltsvinkel | 178 grader |
Synsvinkel (vertikal) | 178 grader |
Responstid | 6 ms |
Kommercielle funktioner | SMART Signage Platform |
Driftstider/-dage | 24 / 7 |
Egenskaber | Daisy Chain |
Standardmontering af fladt panel | 900 x 600 mm |
---|---|
VESA-kompatibilitet | Ja |
USB Port | Ja |
---|---|
USB Port Antal | 2 |
Konnektivitet | Wi-Fi, LAN, Bluetooth |
---|
Forbindelsestype | 2 x HDMI-indgang DVI 2 x USB Lydindgang Lydudgang RS-232 input RS-232 output Netværk Infrarød input DisplayPort input |
---|
Overensstemmelsesstandarder | UL, TUV, VCCI, C-Tick, BSMI, GOST, cUL, NEMKO, NOM, SASO, CB, FCC Part 15 B, AS/NZS 60950-1, CCC, EMC, PSB, IRAM, IEC 60950-1, EN 60950-1, KC, AS/NZS, GB 9254-2008, NOM-019-SCFI-1998, KN22, K60950-1, cUL No.60950-1, EAC, NOM-001-SCFI-1993 IRAM, EN 55024-2:1998+A1:2001+A2:2003, RCM, IP5X, IS13252, VCCI V-3/2010.04 Class A, CNS 14972, GOST-R 51317 serie, GOST 22505-97, CNS 13438 Class A ITE EMI, CNS 13439 AV EMI, GB 17625.1-2012, BIS, INMETRO, GB 4943.1-2011, AS/NZS CISPR 22:2009, KCC/EK, EN 55022:2006+A1:2007 |
---|
Strømenhed | Strømforsyning |
---|---|
Nominal spænding | AC 120/230 V (50/60 Hz) |
Strømforbrug-sovemodus | 0.5 Watt |
Strømforbrug (fra-tilstand) | 0 Watt |
Vægt (forsendelse) | 144 kg |
---|
Min. driftstemperatur | 0 °C |
---|---|
Maks. driftstemperatur | 40 °C |
Fugtighedsgrad ved brug | 10 - 80 % (ikke-kondenserende) |
