Samsung 32" Public Display PM32F

1920x1080, 500 nits, Tizen, Speakers, DVI/2xHDMI/DP

Varenummer: 900194 / Producentens varenr: LH32PMFPBGC/EN

More pictures from Samsung 32" Public Display PM32F

Fri fragt
Ikke på lager. 23 stk. Ubekræftet 9.apr.2020 fra producenten.
60 dages åbent køb
Fri retur
Fri fragt over 1000,-
Retningslinjer for produktanmeldelser

Samsung 32" Public Display PM32F

Premium TIZEN-powered displays built to handle any business need in a slim, captivating design.

  • All-in-one display solution with embedded MagicInfo Player S4 powered by TIZEN™
  • IP5x certification and non-glare panel to withstand a range of environmental conditions
  • Sleek design with slim depth (29.9mm) and narrow bezels (6.9mm)

The all-new embedded media player powered by TIZEN™

The new 2016 SMART Signage that supports SSSP 4.0 allows for a stronger, faster and more stable performance than its previous models. Transcending past hardware performance, the new SSSP 4.0 enables CMS partners to develop and deploy advanced web applications which can help to effectively manage content and SMART Signage for their customers.

Offering robust options for content creation, scheduling and deployment tools

A key aspect of the enhanced TIZEN-based SSSP 4.0 platform, Samsung’s MagicInfo Player S4 enables users to fully leverage the power of their display network from any location through a centralized server. More useable than ever, MagicInfo Player S4 merges a dedicated Backup Player with DataLink content streaming capabilities to reduce the effort needed to share vital information.

Unlock easier and more flexible control due to a centralized infrared receiver

The standalone displays’ integrated centralized infrared receiver (IR) ensures easier and more flexible user control. All models can receive the IR signal on individual panels via Central IR. Through tailored installation or mounting, users can navigate the IR functionality from various locations, further augmenting uninterrupted performance.

Bring an end to unwanted glare and always be assured of high visibility and readability

Equipped with a non-glare frontal panel, the PHF and PMF Series displays reduce natural and ambient light interference to ensure continuous readability in any location. Image visibility and information readability are deemed to be very high, because it is less reflective under light or sunlight, which poses no issues when used with QSR menu boards, or airport flight schedule boards with ample natural light.

Producentens garanti (måneder) 36
Produkttype LED-bagbelyst LCD-fladpaneldisplay
Energiklasse Klasse C
Strømforbrug ved drift 88 Watt
Strømforbrug (Til-modus) 61 W
Energiforbrug om året 85 kWt
Diagonal klasse 32"
Kommercielt brug Ja - digital skiltning
Serie PMF Series
Tv-tuner Ingen radio
TV Tuner Presence Nej
Sensorer Temperatursensor
Video Grænseflade HDMI
HDMI Port Antal 2 porte
PC grænseflade DVI, VGA (HD-15), DisplayPort
Tilstande Stående tilstand, liggende tilstand
Design Narrow Bezel Design, drejeskærm
Beskyttelse Støvsikker
Max Number Of Screens 225
Dimensioner Uden stander
Bredde 72.12 cm
Dybde 2.99 cm
Højde 41.56 cm
Vægt 5.6 kg
Opløsning 1920 x 1080
Display Format 1080p (Full HD)
Billedformatforhold 16:9
Frame Rate og forbedringsteknologi 60 Hz Refresh Rate
LCD-baggrundsbelysningsteknik LED baglys - kantbelyst
Billedkontrastforhold 5000:1
Klarhed 400 cd/m²
Synsfeltsvinkel 178°
Synsvinkel (vertikal) 178°
Responstid 8 ms
Kommercielle funktioner Knaplås, HTML5-support, Auto Source Switching & Recovery
Driftstider/-dage 16 / 7
Egenskaber Multiple Display Control (MDC), MagicInfo, USB Cloning, Mega Dynamic Contrast Ratio, Certified for 16/7 Continuous Operation, SSSP 4.0, Center IR
Stander & Beslag
Stander Valgfri
Standardmontering af fladt panel 200 x 200 mm
Media Player
Storage Drive kapacitet 8 GB
Operativsystem Tizen OS
Type Fjern (standard)
Højttalersystem 2 højttalere
Udgangseffekt/i alt 20 Watt
Højttalere 2 x hovedkanalhøjttaler - indbygget - 10 Watt
Netværk & Internet Multimedie
Konnektivitet Wi-Fi
Forbindelsestype 2 x HDMI
2 x USB
DisplayPort input
DisplayPort output
Multiple Display Control
Seriel input
Seriel output
Udstyr inkluderet Batterier
Medfølgende ledninger Seriel adapter
Overensstemmelsesstandarder Plug and Play, CSA, UL, TUV, VCCI, C-Tick, BSMI, GOST, cUL, NEMKO, NOM, SASO, CB, AS/NZS 60950-1, CCC, PSB, IRAM, EN 60950-1, FCC Part 15 B Class A, KC, GB 9254-2008, NOM-019-SCFI-1998, KN22, KN24, K60950-1, cUL No.60950-1, EAC, GB4943.1-2011, RCM, IP5X, EN55024:1998 + A1:2001 + A2:2003, IS13252, VCCI V-3/2010.04 Class A, CNS 14972, GOST-R 51317 serie, GOST 22505-97, CNS 13438 Class A ITE EMI, CNS 13439 AV EMI, CNS 14409 AV EMS, GB 17625.1-2012, NOM-001-SCFI-1993, BIS, INMETRO, IEC60950-1, CE/EMC, AS/NZS CISPR 22:2009, KCC/EK, EN55022:2006 + A1:2007
Strømenhed Strømforsyning
Strømforbrugs-stand by 0.5 Watt
Strømforbrug (fra-tilstand) 0 Watt
Mål & vægt (forsendelse)
Bredde (forsendelse) 79.6 cm
Dybde (forsendelse) 13.2 cm
Højde (forsendelse) 48.4 cm
Vægt (forsendelse) 7 kg
Miljømæssige parametre
Min. driftstemperatur 0 °C
Maks. driftstemperatur 40 °C
Fugtighedsgrad ved brug 10 - 80 % (ikke-kondenserende)
