| Produktlinje | ASRock Phantom Gaming |
|---|---|
| Model | Z790 NOVA WiFi |
| Producentens garanti (måneder) | 36 |
| EAN | 4710483944482 |
| Understøttet RAM-teknologi | DDR5 SDRAM |
|---|---|
| RAM Slots | 4 DIMM åbninger |
| Kommentarer om kompatible processorer | Understøtter 12./13. og 14. Generation Intel Core / Pentium Gold / Celeron |
| Understøttet RAM (registreret eller buffered) | Ikke bufferet |
| Processor-socket | LGA1700 sokkel |
| Understøttet RAM-integritetskon | Ikke-ECC |
| Model | ATX |
| Chipsættype | Intel Z790 |
| Strømkontakter | 2 x 8-pins ATX12V stikforbindelser, 24-pin hovedstrøm-konnektor |
| RAM-hastighed understøttet | 6800 MHz (O.C.), 6000 MHz (O.C.), 4000 MHz, 4800 MHz, 3600 MHz, 4400 MHz, 5600 MHz (O.C.), 8000 MHz (O.C.) |
| BIOS-egenskaber | UEFI BIOS |
|---|---|
| BIOS-type (Basic Input/Output System) | AMI |
| Hardware egenskaber | DIY Friendly Design, 8 Layer PCB, ASRock Lightning Gaming Ports, ASRock Instant Flash, Server-Grade Low-Loss PCB, ASRock Full HD UEFI, ASRock Easy RAID Installer, Intel Hybrid Technology, 20+1+1 Phase Power Design, ASRock Hyper BCLK Engine, Nahimic Audio Enhacer, 20K sorte kapacitorer, XXL Aluminum Alloy Heatsink, Intel Adaptive Boost Technology (ABT), Forstærkede PCIe-åbninger, ASRock Auto Driver Installer, Intel Thermal Velocity Boost (TVB), Lighting Control, Præmonteret I/O-skjold, Water Pump Header, ASRock My Favorites in UEFI, VRM kølelegemedesign, ASRock EZ Mode, Intel Turbo Boost Max Technology 3.0 |
| USB / FireWire portkonfiguration (samlekasser) | 2 x USB-C 3.2 Gen 2x2 + 4 x USB 3.2 Gen 1 + 4 x USB 2.0 |
|---|---|
| Lagringsporte | 4 x SATA-600 (RAID), 6 x M.2 |
| USB / FireWire portkonfiguration (aktiv) | 1 x USB-C 3.2 Gen 2 + 4 x USB 3.2 Gen 2 + 3 x USB 3.2 Gen 1 + 2 x USB 2.0 |
| USB/FireWire | USB 3.2 Gen 2, USB-C 3.2 Gen 2x2, USB-C 3.2 Gen 1, USB 3.2 Gen 1 |
| Lagring | Blazing M.2 socket, Serial ATA-600 (RAID), Hyper M.2 socket |
| Type | Grafik adapter (CPU påkrævet) |
|---|
| Audio | High Definition Audio (8 kanaler) |
|---|---|
| Audio codec | Realtek ALC4082 |
| Overensstemmelsesstandarder | High Definition Audio |
| Type | Lydkort |
| Netværk controller | Killer E3100G |
|---|---|
| Netværk | 802.11a/b/g/n/ac/ax/be (Wi-Fi 7), 2.5 Gigabit Ethernet, Bluetooth 5.4 |
| Dataforbindelsesprotokol | IEEE 802.11g, IEEE 802.11n, Bluetooth 5.4, IEEE 802.11a, 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6), Fast Ethernet, IEEE 802.11ac, IEEE 802.11be (Wi-Fi 7), Gigabit Ethernet, Ethernet, IEEE 802.11b |
| Medfølgende ledninger | 4 x Seriel ATA kabel |
|---|
| Produkttype | Bundkort |
|---|---|
| Inkluderet tilbehør | Grafikkortholder, 1 til 3 ARGB LED-opdelerkabel, 3 termistorkabler, 5 x standoff til M.2 sokkel, ASRock WiFi 2,4/5/6 GHz antenne, 5 x M.2 skruer |
| Overensstemmelsesstandarder | DisplayPort 1.4, EuP Ready, ErP Ready, HDCP 2.3, FCC |
| Egenskaber | Dobbelt kanal hukommelses arkitektur, Intel Extreme Memory Profiles (XMP) 3.0 |
|---|
| Ekspansionsåbninger | 1 x PCIe 4.0 x16 (x4-modus), 1 x PCIe 3.0 x1, 4 x DIMM 288-pins, 1 x PCIe 5.0 x16 (plads konverterer til x8 tilstand, when SSD er installeret i 1. M.2 plads), 1 x M.2 socket (2230 M.2 Key E-åbning), 6 x M.2 socket (2260/2280 M.2 Key M-åbning), 1 x CPU |
|---|
| Grænseflade (lagring) | PCIe 5.0 -stikforbindelser: 1 x M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5, PCIe 4.0 -stikforbindelser: 4 x M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5, SATA-600 -stikforbindelser: 4 x 7pin Seriel ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5, SATA-600 / PCIe 4.0 -stikforbindelser: 1 - RAID 0 / RAID 1 / RAID 10 / RAID 5 |
|---|
| Interface | 3 x USB-C 3.2 Gen 1, 1 x audio linje-ud - mini-jack, 1 x mikrofon - mini-jack, 2 x USB 2.0, 1 x DisplayPort, 1 x USB-C 3.2 Gen2x2, 4 x USB 3.2 Gen 2, 1 x SPDIF-ud, 1 x HDMI, 2 x antenne, 1 x LAN (2.5Gigabit Ethernet) |
|---|
| Interne interfaces | 2 x USB-C 3.2 Gen 2x2 - intern stik, 1 x SPI - intern stik, 4 x USB 3.2 Gen 1 - intern stik, 1 x Thunderbolt - intern stik, 4 x USB 2.0 - intern stik, 1 x audio - intern stik |
|---|
| Software inkluderet | ASRock Phantom Gaming Tuning, ASRock Polychrome SYNC, Killer Control Center |
|---|
