ASUS B85M-G, S-1150, PC-PROD RESERVEDEL

Varenummer: 782480 / Producentens varenr: B85M-G

More pictures from

Micro-ATX B85 features high-endurance 5X Protection and new UEFI BIOS

  • ASUS 5X Protection: All-round protection provides the best quality, reliability, and durability
  • USB 3.0 BOOST (UASP Support): 170% faster transfer speeds than traditional USB 3.0
  • Network iControl: Real-time network bandwidth management
  • Fan Xpert :Dedicated CPU and case fan controls
  • CrashFree BIOS 3: Restore corrupted BIOS data from USB storage
  • AI Suite 3: One-stop access to innovative ASUS features

ASUS 5X Protection

All-round protection provides the best quality, reliability, and durability

ASUS motherboards guard your PC with 5X Protection. We use quality components like DIGI+ VRM digital power design for precise CPU power on demand, ESD units tested to strict standards that eliminate electrostatic interference, and resettable fuses around DRAM slots to prevent overcurrent and short-circuit damage. We also use corrosion-resistant back I/O shields, all examples of ASUS providing the best possible reliability and durability.

New UEFI BIOS – friendlier and more Intuitive

Exclusive EZ Mode adds useful info to become even easier

Media-renowned UEFI BIOS from ASUS provides the smoothest mouse-controlled graphical BIOS, and now features more intuitive functions to quickly take you to favorite BIOS pages and frequently-accessed settings through custom shortcuts. You can even write quick notes in-BIOS for future reference, view an activity log of setting changes and modifications, and rename SATA ports. EZ Mode has a whole new look, upgraded with extra-friendly capabilities like detailed fan controls, XMP profile settings, SATA information, and fast clock adjustment. Together, these perfect your BIOS experience.

4K Ultra HD ready

Discover future visual experiences

Following up on popular 1080p full HD, 4K Ultra HD is the next big thing, and you’re ready for the upgrade thanks to integrated graphics that natively support up to 4096 x 2160 via HDMI or DisplayPort. That’s four times the pixel count of 1080p (1920 x 1080), offering incredible visual clarity, detail, and realism.

USB 3.0 Boost (UASP Support)

170% faster transfer speeds than traditional USB 3.0

ASUS USB 3.0 Boost technology supports UASP (USB Attached SCSI Protocol) in Windows 8. With USB 3.0 Boost technology, a USB device's transmission speed is significantly increased up to 170%, adding to already fast USB 3.0 performance. ASUS software automatically accelerates data rates for compatible USB 3.0 peripherals without any user interaction

  • World’s 1st USB 3.0 UASP support – instantly 170% faster.
  • Complete USB 3.0 solution – performance boost under Turbo Mode or UASP Mode for most USB devices.
  • Simple plug and boost – auto detection design ensures best performance.

Q-DIMM

Easy memory removal

Even if you work with a smaller case, plugging in memory is easy with one-sided clips that are right at the edge of the board and always accessible. Just push down on the clip and push or pull RAM modules in or out – couldn’t be simpler!

AI Suite 3

One-stop access to innovative ASUS features

ASUS AI Suite 3 offers a brand new user experience through a clearer and more attractive interface with support for larger monitors. It consolidates all exclusive ASUS features into one simple-to-use package, allowing you to supervise overclocking, energy consumption, fan speeds, voltages and more. This all-in-one app offers diverse and easy to use functionality, with no need to switch back and forth between different utilities.

Included:

  • User manualg
  • I/O-shield
  • 2 x SATA 6Gb/s-cable(cables)
Generelt
Producentens garanti (måneder) 36
Produkttype Bundkort - micro-ATX
Chipsættype Intel B85 Express
Processor-socket LGA1150 sokkel
Max antal processorer 1
Kompatible processorer Pentium, Celeron, Core i5, Core i3, Core i7
Understøttet RAM
Maks. størrelse 32 GB
Teknologi DDR3
Bus Clock 1600 MHz, 1333 MHz, 1066 MHz
Understøttet RAM-integritetskon Ikke-ECC
Registreret eller buffer Ikke bufferet
Egenskaber Dobbelt kanal hukommelses arkitektur
Grafik
Maks. allokeret RAM-størrelse 1024 MB
Audio
Type HD Audio (8-kanaler)
Audio codec Realtek ALC887-VD2
Overensstemmelsesstandarder High Definition Audio
LAN
Netværk controller Realtek RTL8111G
Netværks interfaces Gigabit Ethernet
Ekspansion / Konnektivitet
Ekspansionsåbninger 1 x CPU
4 x DIMM 240-pins
1 x PCIe 3.0 x16
2 x PCIe 2.0 x1
Grænseflade (lagring) SATA-600 -stikforbindelser: 4 x 7pin Seriel ATA - 4 enheder
SATA-300 -stikforbindelser: 2 x 7-pin Seriel ATA - 2 enheder
Interface 1 x PS/2-tastatur
1 x PS/2-mus
2 x USB 3.0
1 x LAN (Gigabit Ethernet)
1 x VGA
1 x DVI-D
1 x HDMI
4 x USB 2.0
1 x audio linje-ind - mini-jack
1 x mikrofon - mini-jack
1 x audio linje-ud - mini-jack
Interne interfaces 4 x USB 2.0 - intern stik
2 x USB 3.0 - intern stik
1 x SPDIF ud - intern stik
1 x audio - intern stik
1 x seriel - intern stik
1 x parallel - intern stik
Strømkontakter 4-pin ATX12V konnektor, 24-pin hovedstrøm-konnektor
Egenskaber
BIOS-type (Basic Input/Output System) AMI
BIOS-egenskaber DMI 2.0-understøttet, WfM 2.0 understøttet, Flersproget BIOS, ASUS MyLogo2, ASUS Quiet Thermal Solution, ASUS EZ Flash 2, ACPI 2.0a support, UEFI BIOS, SMBIOS 2.7 support
Sov/ Vågn Aktivering af LAN (wake on LAN = WOL), ringningsaktiveret (WOR) [wake on ring]
Hardware egenskaber Jack retasking, ASUS Anti-Surge Protection, ASUS Q-Design, ESD Guards, Q-DIMM, GPU Boost, ASUS EZ DIY, Q-Slot, CrashFree BIOS 3, All-Solid Capacitor motherboard Design, audio jack detektions teknologi, ASUS EPU (Energy Processing Unit), ASUS Fan Xpert, Intel Turbo Boost Technology 2.0, ASUS DIGI+ VRM, ASUS USB 3.0 Boost teknologi, ASUS Network iControl, ASUS 5X PROTECTION, 4K Ultra HD-klar
Diverse
Udstyr inkluderet I/O- bagvæg
Medfølgende ledninger 2 x Seriel ATA kabel
Med software Drivers & Utilities, ASUS EZ Flash 2, ASUS AI Charger, ASUS Update, ASUS AI Suite III
Kompatibel med Windows 7 Udstyr og software der er "Kompatibel med Windows 7" har Microsofts forsikring i at disse produkter har bestået kompatibilitets- og pålidelighedsprøver med 32-bit og 64-bit Windows 7.
Overensstemmelsesstandarder Plug and Play, ACPI 2.0a, ErP Ready
Bredde 23.3 cm
Dybde 19.3 cm
