Corsair RM750, 750W PSU

Varenummer: 796967 / Producentens varenr: CP-9020055-EU

More pictures from




Corsair RM750 PSU



Fully modular and optimized for silence and high efficiency.



It's built with low-noise capacitors and transformer.



Guaranteed to deliver clean, stable, continuous power!

Introduction:

The Corsair RM750 is fully modular and optimized for silence and high efficiency. It's built with low-noise capacitors and transformers, and Zero RPM Fan Mode ensures that the fan doesn't even spin until the power supply is under heavy load.



And with a fan that's custom-designed for low noise operation, it's whisper-quiet even when it's pushed hard.





Features:




80 PLUS Gold-certified efficiency


Highly efficient RM Series power supplies produce less heat and have lower operating costs. Designed with capacitors and transformers carefully selected to eliminate coil whine and other background noise that can be annoying in quiet environments!

80 PLUS Gold rated efficiency saves you money on your power bill, and the low-profile black cables are fully modular, so you can enjoy fast, neat builds. And, like all Corsair power supplies, the RM750 is built with high-quality components and is guaranteed to deliver clean, stable, continuous power. Want even more? Connect it to your Corsair Link system (available separately) and you can even monitor fan speed and +12V current directly from your desktop.




Zero RPM Fan Mode



The efficient design of the RM750 means minimal excess heat generation, so the fan doesn't even need to spin under low to medium loads.



And when you're pushing it hard, the thermal sensor controls the fan speed to ensure that it gets the cooling it needs without any extra noise


Flat black, low-profile modular cables

You can use only the cables you need, and leave the rest in the box for fast, easy, and great-looking builds.



Reliable, continuous power delivery

Power ratings are continuous, not peak, for superior protection for your valuable PC. Corsair uses high-quality internal components, and the RM750 is guaranteed to deliver clean, stable, continuous power.




Corsair Link compatible



Want even more? RM Series power supplies connect to Corsair Link hubs (available separately) for real-time monitoring of fan speed and power delivery directly from your desktop.



Features

  • 80PLUS Gold certified, delivering over 92% energy efficiency at real world load conditions
  • The completely modular cable system allows you to use only the cables you need
  • Low-profile, flat cable design reduces air friction and helps maximize airflow through your computer's chassis.
  • High-quality capacitors provide uncompromised performance and reliability
  • A five year warranty and lifetime access to Corsair's legendary technical support and customer service
  • Active Power Factor Correction (PFC) with PF value of 0.99
  • Universal AC input from 100~240
  • Over-voltage, over-current protection, under-voltage protection, short circuit protection, over power protection, and over temperature protection provide maximum safety to your critical system components
  • Safety and Agency Approvals: FCC, ICES, CE, C TUV US, RCM, TUV, CB, CCC, BSMI, GOST, ROHS, WEEE, ROHS, KC, TUV-S



Generelt
Producentens garanti (måneder) 60
Enhedstype Strømforsyning - aktiv Power Factor Correction (PFC) - intern
Specifikationsoverensstemmelse ATX12V 2.4/ EPS12V 2.92
PSU formfaktor ATX
Lokalisering Europa
EAN 843591031301
Strømenhed
Indgangspænding AC 100-240 V
Nødvendig frekvens 47 - 63 Hz
Detaljer om strømudgangskonnektorer 1 x strøm 24 pin ATX med aftagelig 4 pin sektion
1 x strøm 8 pin EPS12 V med aftagelig 4 pin ATX12V sektion
7 x 4-PIN intern strøm
8 x 15 pin Serial ATA strøm
2 x 4-PIN mini-strømforsyningsforbinder
4 x 8 pin PCI Express-strøm med aftagelig 2 pin sektion
Udgangspænding +3.3, +5, ±12 V
Strømkapacitet 750 Watt
Output Current +3.3V - 25 A
+5V - 25 A
+12V - 62.5 A
-12V - 0.8 A
+5VSB - 3 A
Effektivitet 92%
Modulær Kabel Administration Ja
80 PLUS certificering 80 PLUS Gold
Diverse
Udstyr inkluderet Kabelbånd, monteringspakke, kabelpose
Medfølgende ledninger Strømkabelpakke
MTBF (forventet tid mellem fejl) 100,000 timer
Egenskaber Corsair Link, beskyttelse mod overstrøm, overspændingsbeskyttelse, overbelastningsbeskyttelse, beskyttelse mod underspænding, kortslutnings beskyttelse, Multi-GPU Technologies Supported, temperatur kontrolleret blæser, Zero RPM-blæsermodus, fuld modulær
Overensstemmelsesstandarder TUV, BSMI, GOST, TUV S, CB, CCC, FCC, RoHS, WEEE, ICES, cTUVus, KC
Producentgaranti
Service & Support Begrænset garanti - 5 år
Mål og vægt
Bredde 15 cm
Dybde 18 cm
Højde 8.6 cm
Vægt 3.23 kg
Mål & vægt (forsendelse)
Vægt ved forsendelse 3.68 kg
