EKWB EK-CoolStream RAD XTC 280 Radiator
Finally EK is ready to offer you radiators designed for hardest enthusiasts. Radiator is optimized for maximum heat dispatching even at lowest fan speeds.
Choosing EK-CoolStream RAD XCT will give your watercooling system a boost you needed to cool your hot hardware!
Finally EK is ready to offer you 140 series radiators designed for hardest enthusiasts. Radiator is optimized for maximum heat dispatching even at lowest fan speeds. Choosing EK-CoolStream RAD XTC will give your watercooling system a boost you needed to cool your hot hardware
Quality at EK level and an optimal price-performance ratio make these EK-CoolStream RAD XTC radiators unique. The new radiators feature, besides their great design and high build quality, great cooling performance. The copper fins are specially designed for Ultra-silent fans (with low Airflow). The parallel coolant channels reduce flow resistance to a minimum. On both sides of the radiator the M3 threads are integrated to allow fan installation on both sides and radiator mounting.
The radiator has integrated G1/4" threads, allowing installation of virtually all common fittings.
Please note: Over-tightening of the screws may damage the radiator. Always take care that the screws do not damage the radiator. Damages of the product because of improper use are not covered by the warranty!
Due to immense variety of fittings/barbs available on market and no prescribed standards, we guarantee compatibility only for connectors bought from our web site.
EKWB EK-CoolStream RAD XTC (280) includes following items:
1x EK-CoolStream RAD XTC 280 (dual) radiator
8x M3 x 30mm DIN965 screws
8x M3 x 5mm DIN965 screws
2x G1/4 plug with allen key
- Copper fins
- Brass chambers
Dimensions: (LxWxH): 317x145x55mm
Connection threads: G1/4"
Fins/inch (FPI): 10
Fins/cm (FPC): 3,85
Weight: Approx. 1215g
Liquid Capacity: Approx. 390 ml (13,19 fl oz)
Fan installation: 4 x M3 threads on both sides each (for 2x140mm fan each)
Pressure tested: 1bar
